INDIRECT FIRED LINE HEATERS

Mar-Quinn Industries’ Ltd. custom indirect-fired line heaters provide a clean heat source with minimal power requirements. Indirect-fired line heaters use a secondary heat exchanger to separate the process gas from the combustion gas. The heaters are water or glycol bath type, and can be supplied with a gas or diesel fire tube.


Depending on your application, Mar-Quinn Industries Ltd. can custom design line heaters ranging from 250,000 up to 4,000,000 BTUs. As well, CO2 injection line heaters up to 3,750,000 BTU can be manufactured.

MAR-QUINN LINE HEATER OPTIONS

  • Sweet, Sour or NACE
  • Various sizes and working pressure coils w/ standard or low temperature service
  • 1”, 2”, 3” and 4” single coil or split bundle
